Victron Cyrix Li-Load Relay 24/48V-230A
Victron Cyrix Li-Load Relay 24/48V-230A
10 customers are viewing this product

Victron Cyrix Li-Load Relay 24/48V-230A


or 4 interest-free payments of  $57.25 with

Subtotal: $229.00


  • Lithium-Ion Compatible
  • Intelligent Load Relay
  • Disengages Load when Control Input is Free Floating
  • 230Amp
  • 24/48V

The LiFePO4 Battery: Preventing cell under voltage, over voltage and over temperature

The first line of protection is cell balancing. All Victron LiFePO4 batteries have integrated cell balancing. The second line of protection consists of:

  • shut down of the load in case of imminent cell under voltage, and
  • shut down or reduction of the charging current in case of imminent cell over voltage, high temperature (>50°C) or low temperature (<0°C).

The VE.Bus BMS is the core of the second protection line. However, not all loads or chargers can be controlled directly by the VE.Bus BMS. In order to shut down such loads or chargers several VE.Bus BMS controllable Cyrix switches are available.

Cyrix Li-Load:

The Cyrix-Li-load will disengage when its control input becomes free-floating. If the battery voltage recovers after disconnecting (which will happen when no other loads are connected to the battery), the output of the BMS will become high and the Cyrix will reengage after 30 seconds. After 3 attempts to reengage, the Cyrix will remain disengaged until the battery voltage has increased to more than 13V (resp. 26V or 52V) for at least 30 seconds (which is a sign that the battery is being recharged). Alternatively, a BatteryProtect can be used (advantage: very low power consumption).

More about Victron:

Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Their products are widely considered to be a professional choice for independent electric power. Efficiently combining two or more distinct power sources is what they do best. Their products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.

Continuous current and breaking capacity at 12 V or 24 V

230 A

Breaking capacity at 48 V

80 A

LED status indication


Control cable

Included (length 1 meter)

Control input

The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low

Connect voltage See text
Disconnect voltage
See text
Current consumption when open
<4 mA
Protection category
65 x 100 x 50mm


Please see more details in the 'Data Sheets' tab.
