BluEdge 12V 100Ah / 200A Continuous Discharge LiFePO4 Battery with Bluetooth + RS485 + CAN bus
BluEdge 12V 100Ah / 200A Continuous Discharge LiFePO4 Battery with Bluetooth + RS485 + CAN bus
BluEdge 12V 100Ah / 200A Continuous Discharge LiFePO4 Battery with Bluetooth + RS485 + CAN bus
10 customers are viewing this product

Lithium Battery | Amptron | BluEdge 12V 100Ah / 200A Continuous Discharge LiFePO4 Battery with Bluetooth + RS485 + CAN bus

$1,036.00
$1,036.00

Read More Below

Subtotal: $1,036.00
Description

The Amptron® BluEdge series batteries are our new premium battery range that raises the bar in quality and sophistication. These batteries are designed using only the highest quality components, with innovative features and a robust, tough and highly waterproof construction that meets the modern demand for reliable long-lasting deep cycle batteries. The design includes exceptionally long-life cells backed with a 5-year warranty, and a smart Battery Management system with integrated communication features including Bluetooth, CAN bus and RS485 interfaces.

The BluEdge series batteries are independently tested to comply with the IEC62619 safety standard and are UN38.3 certified. The batteries also comply with all the requirements of the AS/NZS 3001.2:2022 (“Connectable electrical installations and supply arrangements”) standard for RVs, as well as the marine standard AS/NZS 3004.2:2014 (“Electrical installations—Marinas and boats, Part 2: Boat installations”).Out focus on standards compliance gives you peace of mind for the safe, reliable, and compliant performance of the batteries.

Specifications
Peak discharge current (3 seconds)
400A
Item
Specification
Description/Remark
Model
AT-LFP-12-100-BTC-BV10
BluEdge Series – 12V 100Ah / 200A  Continuous Discharge Lithium LiFePO4 battery + Bluetooth
Size
L-330mm x W-175mm x H-220mm

Weight
12.5kg

Connection Terminals
M8

Connection Terminal Torque Limit
6Nm
Outer Casing Material
ABS

Casing material for single cell
Nickel plated steel

IP Rating
IP66

Chemistry
Lithium iron Phosphate (LiFePO4)

Cell type
Prismatic

Rated Capacity
100Ah/1280WH (at0.2C)

Battery packs in series
Supported (4)

Battery packs in parallel
Supported

Battery cycle life
4000 times (0.2C standard charge & discharge)

Rated voltage / nominal voltage
12.8V

Operating voltage range
10V-14.6V

Shipping voltage
11-14V
Recommended charge voltage
14.4V

Cut-off voltage
10V / When lowest cell reaches 2.5V

Depth of discharge (DoD)
100% Recommended DoD 80%
Batteries can be discharged to 100% of the rated capacity
Standard
(Recommended charge current)
20A

Charging time at recommended charge current
4-5 Hours

Maximum charge current
100A

Max continuous discharge current
200A

Peak discharge current (3 seconds)
400A
Internal resistance
≤ 20mΩ
Operating power consumption
≤ 25mA
Operating temperature
Charge: -0°C~55°C (Ambient)
Discharge: -20°C~60°C (Ambient)
Storage temperature range
Within 2 months -20°C~40°C
Within 6 months -10°C~35°C
Recommended storage temperature
20°C±5°C
Storage humidity range
10%-90%
Recommended storage duration
Charge to 13.3V or 40-60% SOC
every 6 months
Cell over charge protection
3.65V±0.05V
Cell over discharge protection
2.5V±0.1V
Charging over current protection
105A±5A (30s)
Discharging over current protection
1st 210A (30s)
2nd 420A (2s)
Short circuit protection
1000A (560us)

Please see more details in the 'Data Sheets' tab.

Delivery

We don't hold the stock on hand but have a trusted supplier who will send this direct from their nearest warehouse to ensure you receive it as soon as possible.

Warranty

BluEdge 12V 100Ah / 200A Continuous Discharge LiFePO4 Battery with Bluetooth + RS485 + CAN bus Warranty Sheet

Data Sheets

BluEdge 12V 100Ah / 200A Continuous Discharge LiFePO4 Battery with Bluetooth + RS485 + CAN bus Specifications
