Inverter/Charger | Victron | Victron MultiPlus-II 24/3000/70-32 GX
$2,137.54
SKU: PMP242306000
WHY BUY FROM ZERO GRID?
Just me, Landon. Family run. No big corp BS.
My bus runs on this gear. I only sell what I’d use myself.
I’m your sparky. No call centres. No scripts.
Stuff up? Talk to me. I’ll sort it. No overseas runaround.
This is us with 'Sonny' our off grid bus home. Living the dream, slowly travelling Aus
Need a hand? Book a free 10 min chat with me (Landon) →
Description
Victron MultiPlus-II 24/3000/70-32 GX
Features:
- 230V Pure Sine Wave Inverter/Charger
- 24V 3000va Inverter
- 70A Battery Charger
- 32A Automatic Transfer Switch
- Built-In Internal GX
- PowerControl & PowerAssist Functions
An Inverter/Charger with device networking built-in, the MultiPlus-II GX communicates with a solar charger, batteries, and other devices to control a grid-connected, off-grid, or remote power installation. Capable of parallel operation for increased power output, or battery charge rates, the MultiPlus-II GX can also be configured for a three-phase supply. A host of advanced features - such as uninterrupted power supply, setting load limits, and supplementing limited grid-power availability with battery power - can all be controlled straight from your phone or smart device. Remote monitoring is also possible.
More Product Features:
A MultiPlus-II with LCD and GX Functionality:
The MultiPlus-II GX integrates a MultiPlus-II inverter/charger and a GX device with a 2 x 16 character display.
Display and Wi-Fi:
The display reads battery, inverter and solar charge controller parameters. The same parameters can be accessed with a smartphone or other Wi-Fi-enabled device.
GX Device:
The integrated GX device includes:
- A VE.Can interface. This can be used to connect to Victron VE.Can devices (eg VE.Can MPPTs), or the port can be reconfigured via the Remote Console for use with a compatible CAN-bus Li-ion Battery.
- A USB port.
- An Ethernet port.
- A VE.Direct port.
Applications:
The MultiPlus-II GX is intended for applications where additional interfacing with other products and/or remote monitoring is required, such as on-grid or off-grid energy storage systems and certain mobile applications. Only one GX unit is needed in case of Parallel and three-phase operation.
More about Victron:
Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Their products are widely considered to be a professional choice for independent electric power. Efficiently combining two or more distinct power sources is what they do best. Their products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.
Specifications
| PowerControl & PowerAssist |
Yes |
|
Transfer switch |
32 A |
|
Maximum AC input current |
32 A |
|
Auxiliary output |
Yes (32 A) |
|
DC Input voltage range |
19 – 33 V |
|
Output |
Output voltage: 230 VAC ± 2 % Frequency: 50 Hz ± 0.1 % (1) |
|
Cont. output power at 25 °C (3) |
3000 VA |
|
Cont. output power at 25 °C |
2400 W |
|
Cont. output power at 40 °C |
2200 W |
|
Cont. output power at 65 °C |
1700 W |
|
Maximum apparent feed-in power |
3000 VA |
|
Peak power |
5500 W |
|
Maximum efficiency |
94 % |
|
Zero load power |
13 W |
|
Zero load power in AES mode |
9 W |
|
Zero load power in Search mode |
3 W |
|
AC Input |
Input voltage range: 187-265 VAC Input frequency: 45 – 65 Hz |
|
Charge voltage 'absorption' |
28.8 V |
|
Charge voltage 'float' |
27.6 V |
|
Storage mode |
26.4 V |
|
Maximum battery charge current (4) |
70 A |
|
Battery temperature sensor |
Yes |
|
Interfaces |
BMS-Can, USB, Ethernet, VE.Direct, Wi-Fi |
|
External AC current sensor (optional) |
50 A |
|
Programmable relay (5) |
Yes |
|
Protection (2) |
a – g |
|
VE.Bus communication port |
For parallel and three-phase operation, remote monitoring and system integration |
|
General purpose com. port |
Yes, 2x |
|
Remote on-off |
Yes |
|
Operating temperature range |
-40 to +65 °C (fan-assisted cooling) |
|
Humidity (non-condensing) |
max 95 % |
|
Material & Colour |
Steel, blue RAL 5012 |
|
Protection category |
IP22 |
|
Battery-connection |
M8 bolts |
|
230 V AC-connection |
Screw terminals 13 mm² (6 AWG) |
|
Weight |
20kg |
|
Dimensions |
506 x 275 x 147mm |
|
Safety |
EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2 |
|
Emission, Immunity |
EN 55014-1, EN 55014-2 EN-IEC 61000-3-2, EN-IEC 61000-3-3 IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 |
|
Uninterruptible power supply |
IEC 62040-1 |
|
Anti-islanding |
Please consult the certificates on the Victron website |
Please see more details in the 'Data Sheets' tab.
